Parker AC Inverter 690+ up to 1000kw

The AC10 compact drive is one of the smallest variable speed drives available and offers a low cost, compact solution for simple AC induction motor control in applications up to 180kW

The AC10 variable speed compact drive is a simple, reliable and economical solution to every-day motor control applications requiring speed or torque control within the power range of 0.2kW to 180kW. Having compact dimensions and features normally only associated with higher specification AC drives, including, sensorless vector mode, output frequency up to 590 Hz, 3 phase 400VAC supplies in all 5 frame sizes and a full 150 % overload at 0.5 Hz for 1 minute, the AC10 provides an optimised solution for OEM machine builders who are looking for a compact, cost-effective, energy saving variable speed ac drive without compromising on performance.

ENQUIRE NOW

Product OverviewTech SpecificationsProduct Support
Features:

The AC690+ can be user configured for 3 different modes of operation :

Open-loop (volts/frequency) control
  • This mode is ideal for basic motor speed control, or multiple motors driven in parallel. The quick set-up menu and plain language display ensures the quickest and easiest, trouble free start up.
Sensorless vector control
  • High starting torque and tight speed regulation is provided by a sophisticated MRAS (Model Reference Adaptive System) motor control strategy. MRAS provides accurate speed simulation (without the need for any speed measuring transducer) by continually modelling the motor.
Closed-loop vector control
  • Full closed-loop flux vector performance can be achieved with the AC690+ by simply adding an encoder feedback ‘technology box’. This provides 100% continuous full load standstill torque plus a highly dynamic speed loop (up to 45 Hz bandwidth) ; more than sufficient for the most demanding of applications.
Advantages:
  • Pre-programmed application macros
  • Open standard fieldbus communications
  • Programming identical to DC590+ DC drives
  • Mechanical protection options to suit all environments : IP 20 – IP40/NEMA 1 – IP54 – Through panel mounting
  • Class B EMC filters
  • Energy Saving (fast return on investment in pump and fan applications)
  • Supplied in an enclosure for power ratings above 355kW
  • Improved HVAC control
Standards:

The AC690+ series meets the following standards when installed in accordance with the relevant product manual:

  • CE Marked to EN50178 (Safety, Low Voltage Directive)
  • CE Marked to EN61800-3 (EMC Directive)
  • UL listed to US Standard UL508C
  • cUL listed to Canadian Standard C22.2 #14
Technical Specification:
Power Supply

Single Phase Units

  • 220-240VAC +/- 10 %, 50-60 Hz +/- 5% (0.37 to 2.2kW) Three Phase Units
  • 220-240VAC +/- 10 %, 50-60 Hz +/- 5% (0.37 to 37 kW)
  • 380-460VAC +/- 10 %, 50-60 Hz +/- 5% (0.75 to 1000kW)
  • 380-500VAC +/- 10 %, 50-60 Hz +/- 5% (2.2 to 110kW)
Environment:
  • 0-45°C (Constant torque / 40°C with IP40 cover / derate to 50°C)
  • Up to 1000m ASL (derate 1% per 100m above 1000m)
Protection:
  • IP 20 – IP40/NEMA 1 – IP54
Overload:
  • Constant torque rating : 150% for 60 seconds, 180% for 1 second
  • Variable torque rating (pumps and fans) : 115% for 10 seconds
Output Frequency:
  • 0-480Hz
Switching Frequency:
  • Frame B = 3, 6 or 9kHz / Frame C, D, E and F = 3 or 6kHz – All with audibly silent switching frequency.
Dynamic Braking:
  • Each drive can be fitted with an internal dynamic brake switch
  • (Frame B and C : standard / Frame D, E and F : optional)
Analogue Inputs:
  • 4 Configurable, 10bits (13 bits with optional system card) / 0-10V, 0-±10V, 0-20mA, 4-20mA
Analogue Outputs:
  • 3 Configurable, 10 bits / 0-10V, 0-±10V, 0-20mA, 4-20mA
Digital Inputs:
  • 7 Configurable, nominal 24Vdc (30V dc max)
Communication Interface:
  • – RS485 / -MODBUS
PERFORMANCE CHARACTERISTICS
OUTPUT RATING (KW) 0.75 – 1000kW
INPUT VOLTAGE 1*230VAC | 3*230VAC | 3*380-480VAC | 3*500VAC
OPERATING CONTROL MODES V/Hz | Sensorless Vector | Closed Loop Vector
COMMUNICATION INTERFACES RS232 / RS485 | CANopen | ControlNet | DeviceNet | Profibus | Ethernet TCP/IP | Johnson Metasys | Link Communications | Modbus | Siemens Apogee | LonWorks
CERTIFICATES CE (EMC & LVD) | UL Listed | cUL Listed
OPERATING TEMPERATURE (C) 0-45C / 0-40C with IP40 cover (derate up to 50C max)
OPERATING TEMPERATURE (F) 32-113F / 32-104F with IP40 cover (derate up to 122F max)
OPERATING ALTITUDE Up to 1000m ASL (derate > 1000m)
OVERLOAD RATINGS Heavy Duty Rating (Constant Torque) : 150% for 60s | Heavy Duty Rating (Constant Torque) : 180% for 1s | Normal Duty Rating (Variable Torque – pumps and fans) : 115% for 10s
